The crawler mobile jaw crusher plant is designed for primary crushing and flexible on-site operation. Equipped with a heavy-duty jaw crusher, it can process hard rock, quarry stone, construction waste and other materials with stable performance and easy relocation.
With a diesel-electric hybrid drive, compact structure and integrated feeding, crushing and conveying system, this plant is suitable for quarrying, mining, aggregate production, road construction, recycling projects and tunneling applications.
| Model | LDC96 | LDC106 | LDC110 | |
|---|---|---|---|---|
| Feeder | Loading height (mm) | 4200 | 4200 | 4500 |
| Stockpile volume (m³) | 4 | 5 | 6 | |
| Jaw crusher | Max. feeding size (mm) | 400 | 650 | 750 |
| Max. output size (mm) | 180 | 240 | 270 | |
| Main belt conveyor | Discharge height (mm) | 3200 | 3600 | 3800 |
| Size (length × belt width) | 10m×B1000mm | 13m×B1000mm | 14m×B1000mm | |
| Side belt conveyor | Stockpile height (mm) | 1750 | 1750 | 1750 |
| Size (length × belt width) | 4.3m×B650mm | 4.3m×B650mm | 4.3m×B650mm | |
| Overall plant | Crushing capacity (t/h) | 65-275 | 110-400 | 190-625 |
| Total power (kW) | 117 | 137 | 167 | |
We will provide a tailored solution design that meets your needs. From single units to complete EPC+O turnkey plants, we ensure your project starts with precision.
Contact Us
A crawler mobile jaw crusher plant is suitable for quarrying, mining, aggregate production, road construction and construction waste recycling. It is especially useful for projects that require flexible on-site crushing and frequent relocation between job sites.
A crawler mobile jaw crusher can process hard rock, quarry stone, granite, basalt, limestone, construction waste and other materials used in aggregate, mining and infrastructure projects.
